VB18B Mini Bus Air Conditioner

VB14B/VB16B/VB18B Mini Bus Air Conditioner
Features
  • The roof-mount layout makes the mini bus air conditioner convenient to open and overhaul.
  • The fashionable streamline design perfectly integrates with the bus body and reduces air resistance in driving.
  • With its high quality fiberglass epoxy resin case and cover, the mini bus air conditioner has high strength and high resistance to vibration and corrosion.
  • World-brands refrigeration key parts assure the reliable working performance and super quality.
  • The water-proof electric fittings efficiently increase the system's reliability and lifespan of the electric parts.
  • It has abundant cooling capacity, low noise and lower power consumption. This air conditioner is used for 6-7m bus.
Technical specifications
Model VB18B
Standard Cooling Capacity 18kW (15480 Kcal/h, 61300 Btu/h)
Max Cooling Capacity 20kW (17200Kcal/h, 68112 Btu/h)
Refrigerant HFCR134a
Compressor Model UX330/TM31
displacement 330cc/313cc
Evaporator Type Cooper Tube & Aluminum fins
Blower Type Double Axle Centrifugal Flow
Blower Quantity 4
Blower Output 2800 m3/h
Condenser Type Cooper Tube & Aluminum fins
Fan Type Axial Flow
Fan Quantity 2
Fan Output 4000 m3/h
Control System Bus Interior Temperature 16℃-27℃ Adjustable
Defrosting Protection 2℃
High Pressure Protection 2.5Mpa
Low Pressure Protection 0.05Mpa
External Dimension 2430×1500×220 mm
Total current ≤32A(24V)
Applying Buses Coaster/Rosa 7-7.5m mini buses

Note: One year (12 months) warranty period since the date the products have been installed.

As a China-based mini bus air conditioner manufacturer, VehiClima Industry also provides APU truck air conditioner, container truck refrigeration unit, city bus air conditioner, articulated bus air conditioner, and more.
